1. Overview of Hot Rolled Steel Plate
Hot-rolled steel plate is a type of steel material produced through the hot rolling process. This process involves heating steel slabs and then rolling them through rollers at high temperatures to form the final steel plate. Hot rolling alters the internal structure of the steel, providing favorable mechanical and physical properties.
Hot-rolled steel plate is an essential material in industry, widely used across multiple sectors. The main characteristic of hot-rolled steel plate is that it is manufactured at high temperatures, resulting in steel sheets with both high strength and ductility. Thanks to these properties, hot-rolled steel plates have diverse applications and play a vital role in industrial production.
2. Features of Hot Rolled Steel Plate
- Compared with sheets or coils, hot rolled steel plates are known for their outstanding flatness, mechanical properties, and superior performances when it comes to strength, fabricability, toughness, etc.
- Hot rolled steel sheets can be further processed by heat treatment in order to improve their mechanical properties.
3. Parameter of Hot Rolled Steel Plate
Standard | JIS / EN / ASTM / GB Standard |
Grades |
SS400/SM490A/B/YA, SPV235/315/355, SEV245/295/345 |
SB410/450/480, SGV410/450/480 |
|
SMA400AW/BW/CW,SMA490AW/BW/CW,SMA570W etc. |
|
S235JR/J0/J2+N/NL,S275JR/J0/J2+N/N/NL |
|
S355JR/J0/J2+N/K2+N/M/ML,S420N/NL,S460N/NL,S355G8+N |
|
S460Q/QL/QL1, S500Q/QL/QL1, S550Q/QL/QL1,S620Q/QL/QL1,S690Q/QL/QL1 |
|
P275NH, P355N/NH,P500Q/QH/QL1/QL2 |
|
20MnMoNi45, 13Cr Mosi5-5, 11MnNi5-3, 13MnNi6-3, S235J0W/J2W, S355J0W/J2/K2W etc. |
|
A36,A572 Gr.50,A283Gr.C, ASTM A515Gr.60/65/70 |
|
ASTM A516Gr.60/65/70(HIC), ASTM A709Gr. ASTM A533 Gr.A/B/C/D |
|
50/50W-A-F1/50W-B-F1/50W-C-F1 |
|
ASTM A299 Gr.A/B, ASTM A285Gr.A/B/C, ASTM A537Cl.1/Cl.2/Cl.3 |
|
ASTM A588Gr.A/B/C/K. ASTM A573Gr.58/65/70 etc. P355N/NH, P500Q/QH/QL1/QL2,20MnMoNi45, 13Cr Mosi5-5, 11MnNi5-3, 13MnNi6-3, S235J0W/J2W, S355J0W/J2/K2W etc. A/B/D/E,A32/D32/E32/F32,A36/D36/E36/F36,A40/D40/E40/F40, |
|
A131A/B/D/E,AH32/AH36/DH36/EH36/AH40/EH40 |
|
API 5L Gr.B,X42/X46/X52/X56/X60/X65/X70/X80/X100 |
|
NVA420/D420/E420,NVA460/D460/E460,NVA500/D500/E500,NVA550,D550/E550 etc. |
|
NR300,NR360,NR400,NR450,NR500,NR550,NR600 |
|
Size |
Size 1 Thickness: 4.5mm—250mm Width: 1000-3500mm Length: 4000-19000 |
Size 2 Thickness: 10mm—150mm Width: 1500-4500mm Length: 4000-19000 |
|
Size 3 Thickness: 8.0mm—700mm Width: 1500-3500mm Length: 4000-19000 |
|
Delivery Condition |
AR / CR / TMCP / N / N+T / Q+T |
UT Test |
JIS / EN / ASTM / GB Standard |
4. Classification of Hot Rolled Steel Plate
- Regular Hot-Rolled Steel Plate
This is the most common type of hot-rolled steel plate, widely used in construction and general industries. It has suitable mechanical properties and durability for a variety of applications. - High-Strength Hot-Rolled Steel Plate
This type offers greater hardness and strength, making it suitable for applications requiring superior mechanical properties, such as bridges, heavy equipment, and large-scale construction projects. - Hardened Hot-Rolled Steel Plate
This steel has undergone heat treatment to increase hardness. It is typically used in applications requiring high durability and load-bearing capacity, such as structural construction and mechanical engineering.
5. Applications of Hot Rolled Steel Plate
- Construction: Frame structures, doors, partitions, I-beams, H-beams, floors, stairs…
- Mechanical Engineering: Machining large mechanical parts, machinery, and equipment…
- Transportation: Truck frames, train cars, railway tracks, automotive components, shipbuilding…
- Household Goods: Shelving, fans, ventilation systems, barrels, metal containers...
